Principal dimensions Mass Designations
Bearing + sleeve Bearing 1) Sleeve 2)
d 1 D B B 3)
2
≈
mm kg –

90 170 43 61 4,6 ▶ 22219 EK AHX 319
200 45 61 7,4 21319 EK AHX 319
200 67 89 11 ▶ 22319 EK AHX 2319

95 165 52 68 5 ▶ 23120 CCK/W33 AHX 3120
180 46 63 5,4 ▶ 22220 EK AHX 320
180 60,3 77 7,3 ▶ 23220 CCK/W33 AHX 3220

215 47 63 9,1 21320 EK AHX 320
215 73 94 14 ▶ 22320 EK AHX 2320

105 170 45 67 4,45 23022 CCK/W33 AHX 322
180 56 72 6,35 ▶ 23122 CCK/W33 AHX 3122
180 69 91 7,7 24122 CCK30/W33 AH 24122

200 53 72 7,5 ▶ 22222 EK AHX 3122
200 69,8 86 10,5 ▶ 23222 CCK/W33 AHX 3222 G
240 80 102 19,5 ▶ 22322 EK AHX 2322 G

115 180 46 64 4,8 ▶ 23024 CCK/W33 AHX 3024
180 60 82 5,95 ▶ 24024 CCK30/W33 AH 24024
200 62 79 8,7 ▶ 23124 CCK/W33 AHX 3124

200 80 102 11 24124 CCK30/W33 AH 24124
215 58 79 9,55 ▶ 22224 EK AHX 3124
215 76 94 13 ▶ 23224 CCK/W33 AHX 3224 G

260 86 109 24 ▶ 22324 CCK/W33 AHX 2324 G

125 200 52 71 6,75 ▶ 23026 CCK/W33 AHX 3026
200 69 93 8,65 ▶ 24026 CCK30/W33 AH 24026
210 64 82 9,6 ▶ 23126 CCK/W33 AHX 3126

210 80 104 11,5 24126 CCK30/W33 AH 24126
230 64 82 11,5 ▶ 22226 EK AHX 3126
230 80 102 15,5 ▶ 23226 CCK/W33 AHX 3226 G

280 93 119 30,5 ▶ 22326 CCK/W33 AHX 2326 G

135 210 53 73 7,35 ▶ 23028 CCK/W33 AHX 3028
210 69 93 9,2 ▶ 24028 CCK30/W33 AH 24028
225 68 88 11,5 ▶ 23128 CCK/W33 AHX 3128 9.3

225 85 109 14,5 ▶ 24128 CCK30/W33 AH 24128
250 68 88 15 ▶ 22228 CCK/W33 AHX 3128
250 88 109 20,5 ▶ 23228 CCK/W33 AHX 3228 G

300 102 130 38 ▶ 22328 CCK/W33 AHX 2328 G

145 225 56 77 8,85 ▶ 23030 CCK/W33 AHX 3030
225 75 101 11,5 24030 CCK30/W33 AH 24030
250 80 101 17 ▶ 23130 CCK/W33 AHX 3130 G

250 100 126 21 ▶ 24130 CCK30/W33 AH 24130
270 73 101 19 ▶ 22230 CCK/W33 AHX 3130 G
270 96 119 26 ▶ 23230 CCK/W33 AHX 3230 G

320 108 140 45,5 ▶ 22330 CCK/W33 AHX 2330 G

SKF Explorer bearing
▶ Popular item
1) For additional bearing data † product table, page 792
2) For additional withdrawal sleeve data † skf com/go/17000-24-1
3) Width before the sleeve is driven into the bearing bore
Product data online † skf.com/go/17000-9-3 833
