Principal dimensions Mass Designations
Bearing + sleeve Bearing 1) Sleeve 2)
d 1 D B B 3)
2
≈
mm kg –

190 310 82 108 26,5 ▶ 23040 CCK/W33 AH 3040 G
310 109 140 34,5 ▶ 24040 CCK30/W33 AH 24040
340 112 140 48,5 ▶ 23140 CCK/W33 AH 3140

340 140 171 57,5 ▶ 24140 CCK30/W33 AH 24140
360 128 160 63 ▶ 23240 CCK/W33 AH 3240
420 138 177 100 ▶ 22340 CCK/W33 AH 2340

200 340 90 117 36,5 ▶ 23044 CCK/W33 AOH 3044 G
340 118 152 47,5 ▶ 24044 CCK30/W33 AOH 24044
370 120 151 61,5 ▶ 23144 CCK/W33 AOH 3144

370 150 184 76 ▶ 24144 CCK30/W33 AOH 24144
400 108 136 68 22244 CCK/W33 AOH 2244
400 144 189 93 ▶ 23244 CCK/W33 AOH 2344

460 145 189 130 ▶ 22344 CCK/W33 AOH 2344

220 360 92 123 40,5 ▶ 23048 CCK/W33 AOH 3048
360 118 153 50,5 24048 CCK30/W33 AOH 24048
400 128 161 76,5 ▶ 23148 CCK/W33 AOH 3148

400 160 195 91,5 ▶ 24148 CCK30/W33 AOH 24148
440 160 197 120 ▶ 23248 CCK/W33 AOH 2348
500 155 197 165 ▶ 22348 CCK/W33 AOH 2348

240 400 104 135 56,5 ▶ 23052 CCK/W33 AOH 3052
400 140 178 75 24052 CCK30/W33 AOH 24052 G
440 144 179 105 ▶ 23152 CCK/W33 AOH 3152 G

440 180 218 120 ▶ 24152 CCK30/W33 AOH 24152
480 130 161 120 22252 CCK/W33 AOH 2252 G
480 174 213 155 ▶ 23252 CCK/W33 AOH 2352 G

540 165 213 205 ▶ 22352 CCK/W33 AOH 2352 G

260 420 106 139 62 ▶ 23056 CCK/W33 AOH 3056
420 140 179 79 ▶ 24056 CCK30/W33 AOH 24056 G
460 146 183 110 23156 CCK/W33 AOH 3156 G

460 180 219 130 ▶ 24156 CCK30/W33 AOH 24156
500 130 163 125 22256 CCK/W33 AOH 2256 G 9.3
500 176 220 160 23256 CCK/W33 AOH 2356 G

580 175 220 245 22356 CCK/W33 AOH 2356 G

280 460 118 153 82,5 23060 CCK/W33 AOH 3060
460 160 202 110 ▶ 24060 CCK30/W33 AOH 24060 G
500 160 200 140 23160 CCK/W33 AOH 3160 G

500 200 242 180 ▶ 24160 CCK30/W33 AOH 24160
540 140 178 155 22260 CCK/W33 AOH 2260 G
540 192 236 200 23260 CCK/W33 AOH 3260 G

300 480 121 157 89 ▶ 23064 CCK/W33 AOH 3064 G
480 160 202 115 24064 CCK30/W33 AOH 24064 G
540 176 217 175 ▶ 23164 CCK/W33 AOH 3164 G

540 218 260 225 24164 CCK30/W33 AOH 24164
580 150 190 185 22264 CCK/W33 AOH 2264 G
580 208 254 250 ▶ 23264 CCK/W33 AOH 3264 G

SKF Explorer bearing
▶ Popular item
1) For additional bearing data † product table, page 792
2) For additional withdrawal sleeve data † skf com/go/17000-24-1
3) Width before the sleeve is driven into the bearing bore
Product data online † skf.com/go/17000-9-3 835
