Page 615 - SKF-bearing-housings

J
J 2

28
H J 1 A 1
G
G 1
H 1
SBPN .. F
H 2
G 2
L

44

28
SBPN .. RA

Shaft Dimensions Mass
diam- Housing Shaft Housing
eter A B
d a G G 1 G 2 b a b b b c b d b e d b d c d d Threads/ d 4 d 5 d 6 r
min. inch
mm/in. – mm in. – mm – mm kg
180 1 UNC NPTF 1/2 NPTF 1.1/4 65 150 130 55 128 200 160 7.063 8 225 250 M 12 5 118 115
7.087
200 1 UNC NPTF 1/2 NPTF 1.1/4 75 170 125 50 138 230 180 7.844 8 265 290 M 12 8 133 147
7.874
220 1 UNC NPTF 1/2 NPTF 1.1/4 75 190 125 50 148 250 200 8.625 8 305 330 M 12 8 189 205
8.661
240 1 UNC NPTF 1/2 NPTF 1.1/4 85 205 130 55 163 275 220 9.439 6 335 360 M 12 8 244 256
9.449
13.3
260 1 UNC NPTF 1/2 NPTF 1.1/2 95 225 130 55 173 300 240 10.189 6 355 380 M 12 8 259 273
10.236
300 1 UNC NPTF 1/2 NPTF 1.1/2 105 250 130 55 188 340 280 11.781 6 435 460 M 12 8 342 358
11.811
320 1 UNC NPTF 1/2 NPTF 1.1/2 115 270 140 65 198 360 300 12.559 6 455 480 M 12 8 445 465
12.598
