Ordering information

grease fitting. Therefore, CARB toroidal roller Ordering information
bearings need customized SBD and THD
housings. For more information, contact the SBD plummer (pillow) block housings and THD
SKF application engineering service. take-up housings are supplied with the appro-
priate covers, labyrinth rings and, if needed,
adapter rings. End plates to secure a bearing
Mounting on a cylindrical seat at the end of a shaft are
not supplied with the housings. Bearings and
SBD and THD housings must be mounted adapter sleeves must be ordered separately.
properly using the appropriate tools and state
of the art mechanical mounting methods. All Order example
associated components must meet certain Two SBD plummer block housings are
basic requirements († Specifications for required for two 22213 E spherical roller
shafts and housing support surfaces on bearings. One housing accommodates the
page 45). non-locating bearing at the end of the shaft.
For information about mounting rolling The other housing accommodates the locating
bearings, refer to the SKF bearing maintenance bearing and a through shaft.
handbook or skf.com/mount. The following items should be ordered:

• 1 housing SBDD 2213 AL
Cover bolt torque specifications • 1 housing SBDD 2213 BF
Cover bolts should be tightened to the torque
values listed in table 5. The cover bolts are in
accordance with ISO-4017.

Mounting and dismounting the adapter
ring 10
The adapter ring, which locks the labyrinth
ring in place, has plain holes for mounting and
threaded holes for dismounting. The adapter
ring bolts should be tightened to the torque
values listed in table 1 on page 491.

Condition monitoring
If connections for condition monitoring sen-
sors are required, contact the SKF application
engineering service.

Accessories

There are several accessories available for
SBD and THD housings, including automatic
lubricators, centralized lubrication systems
and adapters for grease fittings. In some
cases, an adapter is needed to attach the
accessory to the housing. For additional infor-
mation, refer to SKF tools and products
(† page 47).

501
