Page 802 - Rollingbearings

product table p800

9.1 Spherical roller bearings
d 130 – 140 mm
b
K
r 2
r 1
r 1
r 2
D D 1 d d 2 d

B

Cylindrical bore Tapered bore Sealed (2CS5)

Principal dimensions Basic load ratings Fatigue Speed ratings Mass Designations
dynamic static load Reference Limiting Bearing with
limit speed speed cylindrical bore tapered bore
d D B C C 0 P u

mm kN kN r/min kg –

130 200 52 452 610 61 2 800 3 600 6 ▶ 23026 CC/W33 ▶ 23026 CCK/W33
200 52 452 610 62 – 800 6 ▶ 23026-2CS5/VT143 ▶ 23026-2CS5K/VT143
200 69 569 815 81,5 2 000 3 000 8,05 ▶ 24026 CC/W33 ▶ 24026 CCK30/W33

200 69 570 830 81,5 – 600 8,05 ▶ 24026-2CS5/VT143 –
210 64 586 780 78 2 400 3 200 8,8 ▶ 23126 CC/W33 ▶ 23126 CCK/W33
210 80 699 1 000 100 1 700 2 400 11 ▶ 24126 CC/W33 24126 CCK30/W33

210 80 701 1 000 100 – 530 11 ▶ 24126-2CS5/VT143 –
220 73 640 930 93 1 600 2 400 11,5 229750 J/C3R505 –
230 64 758 930 88 2 600 3 600 11 ▶ 22226 E ▶ 22226 EK

230 75 758 930 88 – 700 11 ▶ BS2-2226-2CS5/VT143 ▶ BS2-2226-2CS5K/VT143
230 80 826 1 060 104 1 900 2 600 14,5 ▶ 23226 CC/W33 ▶ 23226 CCK/W33
230 80 828 1 060 104 – 530 14,5 ▶ 23226-2CS5/VT143 ▶ 23226-2CS5K/VT143

280 93 1 176 1 320 114 1 800 2 400 29 ▶ 22326 CC/W33 ▶ 22326 CCK/W33
280 93 1 176 1 320 114 1 800 2 400 29 ▶ 22326 CCJA/W33VA405 ▶ 22326 CCKJA/W33VA405
280 93 1 176 1 320 114 1 800 2 400 29 22326 CCJA/W33VA406 –

280 93 1 178 1 320 114 – 500 29 ▶ 22326-2CS5/VT143 ▶ 22326-2CS5K/VT143
9.1
140 210 53 485 680 68 – 700 6,55 ▶ 23028-2CS5/VT143 ▶ 23028-2CS5K/VT143
210 53 485 680 68 2 600 3 400 6,55 ▶ 23028 CC/W33 ▶ 23028 CCK/W33
210 69 600 900 88 2 000 2 800 8,55 ▶ 24028 CC/W33 ▶ 24028 CCK30/W33

210 69 601 900 88 – 560 8,55 ▶ 24028-2CS5/VT143 –
225 68 659 900 88 2 200 2 800 10,5 ▶ 23128 CC/W33 ▶ 23128 CCK/W33
225 85 796 1 160 112 1 600 2 200 13,5 ▶ 24128 CC/W33 ▶ 24128 CCK30/W33

225 85 797 1 160 112 – 450 13,5 ▶ 24128-2CS5/VT143 24128-2CS5K30/VT143
250 68 743 900 86,5 2 400 3 200 14 ▶ 22228 CC/W33 ▶ 22228 CCK/W33
250 68 744 900 86,5 – 670 14 ▶ 22228-2CS5/VT143 ▶ 22228-2CS5K/VT143

250 88 962 1 250 120 1 700 2 400 19 ▶ 23228 CC/W33 ▶ 23228 CCK/W33
250 88 963 1 250 120 – 480 19 ▶ 23228-2CS5/VT143 ▶ 23228-2CS5K/VT143
300 102 1 357 1 560 132 1 700 2 200 36,5 ▶ 22328 CC/W33 ▶ 22328 CCK/W33
300 102 1 357 1 560 132 1 700 2 200 36,5 ▶ 22328 CCJA/W33VA405 ▶ 22328 CCKJA/W33VA405
300 102 1 357 1 560 132 1 700 2 200 36,5 22328 CCJA/W33VA406 –
300 102 1 359 1 560 132 – 430 36,5 ▶ 22328-2CS5/VT143 ▶ 22328-2CS5K/VT143

SKF Explorer bearing
▶ Popular item
