r a

D a

Dimensions Abutment and illet Associated radial shaft seals 1)
dimensions Single lip Double lip Spring loaded lip
F w r 1,2 D a r a
min max max
mm mm –

110 1,1 123,5 1 – – 110x130x12 HMS5 RG
1,1 123,5 1 – – 110x130x12 HMS5 RG
1,1 123,5 1 – – 110x130x12 HMS5 RG

1,1 123,5 1 – – 110x130x12 HMS5 RG

115 1,1 133,5 1 – – 115x140x12 HMS5 RG

120 1 135 1 – – 120x140x12 HMS5 RG 7.3

125 1,1 143,5 1 – – 125x150x12 HMS5 RG

130 1 145 1 – – 130x150x10 CRSA1 R

135 1,1 158,5 1 – – 135x165x14 HMSA7 R

145 1,1 158,5 1 – – –

150 1,5 172 1,5 – – 150x180x12 HMS5 RG

155 1,1 168,5 1 – – –

160 1,5 182 1,5 – – 160x190x15 HMS5 RG

165 1,1 183,5 1 – – 165x190x15 HMS5 RG

175 1,1 193,5 1 – – 175x200x15 HMS5 RG

185 1,1 208,5 1 – – 185x215x15 HMS42 R

195 1,1 218,5 1 – – –

210 1,5 232 1,5 – – 210x240x15 HMS5 RG

220 1,5 242 1,5 – – 220x250x15 HMS5 RG

240 1,5 262 1,5 – – 240x270x15 HMS5 RG

265 2 291 2 – – Available on request

285 2 311 2 – – 285x320x16 HDS2 R

305 2 341 2 – – Available on request

330 2,1 369 2 – – Available on request

1) For additional information → skf com/seals
