Page 635 - Rollingbearings

r a

D a

Dimensions Abutment and illet Associated radial shaft seals 1)
dimensions Single lip Double lip Spring loaded lip
F w r 1,2 D a r a
min max max
mm mm –

72 1 85 1 – – 72x90x10 HMS5 RG
1 85 1 – – 72x90x10 HMS5 RG

73 1 85 1 – – –
1 85 1 – – –

75 1 87 1 – – 73x92x11 1 CRWH1 R
1 87 1 – – 73x92x11 1 CRWH1 R
1,1 88,5 1 – – 75x95x10 HMS5 RG 7.3

80 1 90 1 – – 80x95x10 HMS5 RG
1 90 1 – – 80x95x10 HMS5 RG
1 95 1 – – 80x100x10 HMS5 RG

1 95 1 – – 80x100x10 HMS5 RG

85 1 100 1 – – 85x105x12 HMS5 RG
1 100 1 – – 85x105x12 HMS5 RG
1 100 1 – – 85x105x12 HMS5 RG

1 100 1 – – 85x105x12 HMS5 RG

90 1 105 1 – – 90x110x10 HMS5 RG
1 105 1 – – 90x110x10 HMS5 RG
1 105 1 – – 90x110x10 HMS5 RG

1 105 1 – – 90x110x10 HMS5 RG

95 1 110 1 – – 95x115x12 HMS5 RG
1 110 1 – – 95x115x12 HMS5 RG

100 1 115 1 – – 100x120x10 HMS5 RG
1,1 113,5 1 – – 100x120x10 HMS5 RG
1 115 1 – – 100x120x10 HMS5 RG

1,1 113,5 1 – – 100x120x10 HMS5 RG

105 1 120 1 – – 105x125x13 HMS4 R
1,1 118,5 1 – – 105x125x13 HMS4 R
1 120 1 – – 105x125x13 HMS4 R

1,1 118,5 1 – – 105x125x13 HMS4 R

1) For additional information → skf com/seals
