Principal dimensions Mass Designations
Adapter sleeve Included products Associated
assembly lock nut locking device hydraulic nut
d 1 d d 3 B 1 B B 4 B 5 G G 2 G 3 A

mm kg –

450 480 560 237 60 – 77 Tr 480x5 M 8 12 6,5 75 OH 3096 H HM 3096 MS 30/500-96 HMV 96E
480 620 335 75 – 95 Tr 480x5 M 8 12 6,5 135 OH 3196 H HM 3196 MS 3196 HMV 96E

500 530 630 265 68 – 90 Tr 530x6 M 8 12 6,5 105 OH 30/530 H HM 30/530 MS 30/600-530 HMV 106E

23.1
