Principal dimensions Thread Mass Designations
Threads Adapter sleeve Included products Associated
per inch assembly lock locking hydraulic nut
d 1 d d 3 B 1 B B 4 B 5 G nut device
max.

in./mm mm in. in. – kg –

9 15 /16 280 13,005 6,181 1,51 – 1,854 11,004 6 20,5 ▶ SNP 3056x9.15/16 N 056 PL 56 HMVC 56E
252,413 280 13,005 7,756 1,51 – 1,854 11,004 6 21 SNP 3156x9.15/16 N 056 PL 56 HMVC 56E

10 280 13,005 6,181 1,51 – 1,854 11,004 6 20,5 ▶ SNP 3056x10 N 056 PL 56 HMVC 56E
254 280 13,005 7,756 1,51 – 1,854 11,004 6 21 ▶ SNP 3156x10 N 056 PL 56 HMVC 56E

10 7 /16 280 13,005 6,181 1,51 – 1,854 11,004 6 20,5 ▶ SNP 3056x10.7/16 N 056 PL 56 HMVC 56E
265,113 280 13,005 7,756 1,51 – 1,854 11,004 6 21 SNP 3156x10.7/16 N 056 PL 56 HMVC 56E
280 13,005 8,937 1,51 – 1,854 11,004 6 27 ▶ SNP 3256x10.7/16 N 056 PL 56 HMVC 56E

10 1 /2 280 13,005 6,181 1,51 – 1,854 11,004 6 20,5 ▶ SNP 3056x10.1/2 N 056 PL 56 HMVC 56E
266,7 280 13,005 7,756 1,51 – 1,854 11,004 6 21 SNP 3156x10.1/2 N 056 PL 56 HMVC 56E

10 15 /16 300 14,193 6,717 1,573 – 1,948 11,785 6 31 ▶ SNP 3060x10.15/16 N 060 PL 60 HMVC 60E
277,813 300 14,193 8,37 1,573 – 1,948 11,785 6 27 ▶ SNP 3160x10.15/16 N 060 PL 60 HMVC 60E
300 14,193 9,63 1,573 – 1,948 11,785 6 31 ▶ SNP 3260x10.15/16 N 060 PL 60 HMVC 60E

11 300 14,193 6,717 1,573 – 1,948 11,785 6 31 ▶ SNP 3060x11 N 060 PL 60 HMVC 60E
279,4 300 14,193 9,63 1,573 – 1,948 11,785 6 31 ▶ SNP 3260x11 N 060 PL 60 HMVC 60E

11 7 /16 320 15,005 6,936 1,666 – 2,041 12,562 6 29,5 SNP 3064x11.7/16 N 064 PL 64 HMVC 64E
290,513

11 1 /2 320 15,005 6,936 1,666 – 2,041 12,562 6 29,5 ▶ SNP 3064x11.1/2 N 064 PL 64 HMVC 64E
292,1

11 15 /16 320 15,005 6,936 1,666 – 2,041 12,562 6 29,5 ▶ SNP 3064x11.15/16 N 064 PL 64 HMVC 64E
303,213 320 15,005 9,101 1,666 – 2,041 12,562 6 33,5 SNP 3164x11.15/16 N 064 PL 64 HMVC 64E
320 15,005 10,361 1,666 – 2,041 12,562 6 44,5 ▶ SNP 3264x11.15/16 N 064 PL 64 HMVC 64E

12 320 15,005 6,936 1,666 – 2,041 12,562 6 29,5 ▶ SNP 3064x12 N 064 PL 64 HMVC 64E
304,8 320 15,005 9,101 1,666 – 2,041 12,562 6 33,5 ▶ SNP 3164x12 N 064 PL 64 HMVC 64E
320 15,005 10,361 1,666 – 2,041 12,562 6 44,5 ▶ SNP 3264x12 N 064 PL 64 HMVC 64E

12 7 /16 340 15,755 7,533 1,791 – 2,166 13,303 5 35,5 ▶ SNP 3068x12.7/16 N 068 PL 68 HMVC 68E
315,913 340 15,755 9,777 1,791 – 2,166 13,303 5 42,5 ▶ SNP 3168x12.7/16 N 068 PL 68 HMVC 68E
340 15,755 11,116 1,791 – 2,166 13,303 5 47,5 ▶ SNP 3268x12.7/16 N 068 PL 68 HMVC 68E

13 7 /16 360 16,505 7,569 1,791 – 2,166 14,17 5 39 ▶ SNP 3072x13.7/16 N 072 PL 72 HMVC 72E
341,313 360 16,505 9,852 1,791 – 2,166 14,17 5 54,5 ▶ SNP 3172x13.7/16 N 072 PL 72 HMVC 72E
360 16,505 11,427 1,791 – 2,166 14,17 5 61,5 ▶ SNP 3272x13.7/16 N 072 PL 72 HMVC 72E

13 15 /16 360 16,505 7,569 1,791 – 2,166 14,17 5 39 SNP 3072x13.15/16 N 072 PL 72 HMVC 72E
354,013 360 17,755 11,867 1,916 – 2,353 14,921 5 66 ▶ SNP 3276x13.15/16 N 076 PL 76 HMVC 76E
380 17,755 7,733 1,916 – 2,353 14,921 5 43 ▶ SNP 3076x13.15/16 N 076 PL 76 HMVC 76E

380 17,755 10,056 1,916 – 2,353 14,921 5 57 ▶ SNP 3176x13.15/16 N 076 PL 76 HMVC 76E

14 360 17,755 11,867 1,916 – 2,353 14,921 5 66 ▶ SNP 3276x14 N 076 PL 76 HMVC 76E
355,6 380 17,755 7,733 1,916 – 2,353 14,921 5 43 ▶ SNP 3076x14 N 076 PL 76 HMVC 76E
380 17,755 10,056 1,916 – 2,353 14,921 5 57 ▶ SNP 3176x14 N 076 PL 76 HMVC 76E

14 15 /16 400 18,505 10,449 2,073 – 2,5 15,709 5 63,5 SNP 3180x14.15/16 N 080 PL 80 HMVC 80E
379,413 23.2

15 400 18,505 8,401 2,073 – 2,5 15,709 5 45,5 ▶ SNP 3080x15 N 080 PL 80 HMVC 80E
381 400 18,505 10,449 2,073 – 2,5 15,709 5 63,5 ▶ SNP 3180x15 N 080 PL 80 HMVC 80E
400 18,505 12,654 2,073 – 2,5 15,709 5 75 ▶ SNP 3280x15 N 080 PL 80 HMVC 80E

15 3 /4 420 19,318 8,488 2,073 – 2,5 16,496 5 47,5 ▶ SNP 3084x15.3/4 N 084 PL 84 HMVC 84E
400,05 420 19,318 11,402 2,073 – 2,5 16,496 5 66 ▶ SNP 3184x15.3/4 N 084 PL 84 HMVC 84E
420 19,318 13,292 2,073 – 2,5 16,496 5 75 ▶ SNP 3284x15.3/4 N 084 PL 84 HMVC 84E

16 1 /2 440 20,505 9,1 2,385 – 2,906 17,283 5 59,5 ▶ SNP 3088x16.1/2 N 088 PL 88 HMVC 88E
419,1 440 20,505 11,817 2,385 – 2,906 17,283 5 68,5 ▶ SNP 3188x16.1/2 N 088 PL 88 HMVC 88E
440 20,505 13,943 2,385 – 2,906 17,283 5 86,5 ▶ SNP 3288x16.1/2 N 088 PL 88 HMVC 88E

▶ Popular item

Product data online † skf.com/go/17000-23-2 1083
