Control units

Features and benefits
Easy installation via top hat rail mounting, One unit for different operating modes such as timer, counter and monitoring functions; other features are adjustable, Pulse generator/counter with adjustable interval time, Time operation or machine clogged operation , Pump run time limitation, Monitoring of pressure build-up, contact (NO), Low-level control and EEPROM as an additional feature

Applications
All single-line lubrication systems for stationary industrial applications

Features and benefits
Universal control and monitoring device, Compact design, Easy to handle operations, Different operating modes such as timer, counter and monitoring functions, Red LED for failure indication and cause, Integrated counters for permanent operation, failed hours and working-hour meter show complete life cycle of system

Applications
Commercial vehicles, Construction machinery, Agriculture

Features and benefits
Easy-to-operate, programmable controller, System monitoring and error detection/failure remedy, Integrated temperature-overload safety device, Up to three lubrication circuits can be controlled or monitored separately

Applications
Special-purpose machinery and general industry, Cement and steel plants, Food and beverage

Features and benefits
Versatile and durable, automatic pump change (Dualset), Modular units provide easy system modification, Compatible with ultrasonic low level sensor, Grease spraying control with air monitoring, Compatible with SKF doser monitor

Features and benefits
Automatic pump change (Dualset), Grease spraying control with air monitoring, IP 65 protection rating, Compatible with SKF doser monitor, Works with SKF online control software

Features and benefits
Simple monitoring via control panel and cover LED signals, All lubrication configurations can be set in field by user interface, Set values and program status at the power failure are stored in an EEPROM-memory; no battery

Applications
Construction machinery, mining applications

Features and benefits
Available for 12 or 24V DC, Suitable for operational environments with extreme temperatures, One-button user interface, Power failure memory

Applications
Service vehicles, Construction machinery, Agriculture machinery

Features and benefits
Designed for control and monitoring in 12/24 V DC lubrication systems, Reliable and durable, one-channel lubrication controller, Supports single-line and dual-line lubrication systems, All lubrication configurations can be set in the field by user, IP 65 rating

Applications
Control of lubrication systems with pneumatic pump SKF 40PGAS and electrical pump SKF Minilube, Small excavators, Wheel loaders, Trucks and buses

Features and benefits
Program timer controls lubication cycle frequency of air-operated, single-stroke pumps, Timer turns pump on/off via solenoid air valves in programmed intervals, Retains memory for three hours during machine shut down or power interruption, Suspended timing during power interruptions eliminates over-lubrication due to pre-lube when machine is frequently started and stopped

Applications
Cement industry, Food and beverage, Assembly lines, Conveyors

Features and benefits
Various alarm condition settings including cycle frequency and alarm triggers, Programming, data logging and reporting, including system resets, downloads to controllers, lubrication activity, lubrication cycles and alarms, Display: LEDs, pump on and system fault (alarm), Controller must be programmed via USB connection to PC, Manual lubrication push-button

Applications
Off-highway vehicles, Mobile equipment use

Features and benefits
Time controller for installation in driver's cabin, Suitable for retrofit, Simple handling of time setting and function control

Applications
Agriculture, Chain lubrication systems

Features and benefits
Easy-to-identify error codes, Visual and audible fault notification, Small footprint; fits in any vehicle cab, Simple to install, Monitors reservoir level, Counts lubrication cycles, Operating temperature range of –15 to +50 °C (5 to 122 °F), 12-volt or 24-volt operation, Timing intervals from five seconds to 24 hours

Applications
Off-road and mobile construction equipment, General industry applications, Chain lubrication systems, Agriculture machinery

Features and benefits
Integrated, flexible lubrication programs, 8 inputs / 5 outputs; suitable for complex lubrication systems, Time- or cycle-dependent control of lubrication intervals, Can be interfaced with common field bus systems

Applications
Lincoln and SKF progressive systems, single-line, dual-line and multi-line systems, Railway lubrication and spray lubrication systems, Food and beverage, Chain lubrication systems like Cobra and PMA

Features and benefits
Integrated, flexible lubrication programs, Basic device with 10 digital inputs, of which two can be used analogously, and eight outputs, Up to seven extension modules can be added, whereby each module has 10 E 8 A just like the basic device, Three lubrication pumps can be controlled and monitored, each of which provides up to three lubrication circuits, Single modules are connected by a bus interface

Applications
Cement ans steel industry, Mining; stationary and mobile excavators, Food and beverage
