PRODUCT
![]()
ชื่อรุ่น :
SPZ/10
แบรนด์
Optibelt
รายละเอียด :
optibelt KS ( SPZ ) มู่เล่ย์ ร่องวี สำหรับรูล็อคทรงกระบอกแบบมาตราฐาน สูงสุด 48 มม.
- ขนาดเส้นผ่าศูนย์กลางของมู่เล่ย์ มีตั้งแต่ 45 - 355 มม.
ดูรูปสินค้าเพิ่มเติมติดต่อเราได้ที่ :
Model
Model description
Price
Model
SPZ 45
Model description
Datum diameter = 45.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 16.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 16.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 16.0 mm ,Hub length l = 35.0 mm
Price
Model
SPZ 50
Model description
Datum diameter = 50.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 20.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 20.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 20.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 56
Model description
Datum diameter = 56.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 20.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 63
Model description
Datum diameter = 63.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 71
Model description
Datum diameter = 71.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 75
Model description
Datum diameter = 75.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 24.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 24.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 80
Model description
Datum diameter = 80.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 35.0 mm
Price
Model
SPZ 85
Model description
Datum diameter = 85.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 35.0 mm
Price
Model
SPZ 90
Model description
Datum diameter = 90.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
Price
Model
SPZ 95
Model description
Datum diameter = 95.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
Price
Model
SPZ 100
Model description
Datum diameter = 100.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
Price
Model
SPZ 106
Model description
Datum diameter = 100.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
Price
Model
SPZ 112
Model description
Datum diameter = 112.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
Price
Model
SPZ 118
Model description
Datum diameter = 118.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
Price
Model
SPZ 125
Model description
Datum diameter = 125.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
Price
Model
SPZ 132
Model description
Datum diameter = 132.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 35.0 mm
3 groove , Finished bore hole dmax. = 40.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 140
Model description
Datum diameter = 140.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 150
Model description
Datum diameter = 150.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 24.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 160
Model description
Datum diameter = 160.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 30.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 170
Model description
Datum diameter = 170.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 40.0 mm ,Hub length l = 30.0 mm
2 groove , Finished bore hole dmax. = 40.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 180
Model description
Datum diameter = 180.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 30.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 190
Model description
Datum diameter = 190.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 30.0 mm
2 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 200
Model description
Datum diameter = 200.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 38.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 212
Model description
Datum diameter = 212.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 38.0 mm
2 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 225
Model description
Datum diameter = 225.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 38.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 250
Model description
Datum diameter = 250.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 38.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 280
Model description
Datum diameter = 280.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 34.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 315
Model description
Datum diameter = 315.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 34.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 38.0 mm
3 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 40.0 mm
Price
Model
SPZ 355
Model description
Datum diameter = 355.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 34.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 40.0 mm
3 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 45.0 mm
Price
