ชื่อรุ่น :
SPB/17
แบรนด์
Optibelt
รายละเอียด :
optibelt KS ( SPB ) มู่เล่ย์ ร่องวี สำหรับรูล็อคทรงกระบอกแบบมาตราฐาน สูงสุด 90 มม.
- ขนาดเส้นผ่าศูนย์กลางของมู่เล่ย์ มีตั้งแต่ 56 - 630 มม.
ดูรูปสินค้าเพิ่มเติมติดต่อเราได้ที่ :
Model
Model description
Price
Model
SPB 56
Model description
Datum diameter = 56.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 20.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 20.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 22.0 mm ,Hub length l = 62.0 mm
Price
Model
SPB 63
Model description
Datum diameter = 63.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 20.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 20.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 22.0 mm ,Hub length l = 62.0 mm
Price
Model
SPB 71
Model description
Datum diameter = 71.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 22.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 22.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 22.0 mm ,Hub length l = 55.0 mm
Price
Model
SPB 75
Model description
Datum diameter = 75.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 25.0 mm ,Hub length l = 62.0 mm
Price
Model
SPB 80
Model description
Datum diameter = 80.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 80.0 mm
Price
Model
SPB 85
Model description
Datum diameter = 85.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 75.0 mm
Price
Model
SPB 90
Model description
Datum diameter = 90.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 75.0 mm
Price
Model
SPB 95
Model description
Datum diameter = 95.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 35.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 67.0 mm
4 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 75.0 mm
Price
Model
SPB 100
Model description
Datum diameter = 100.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 124.0 mm
Price
Model
SPB 106
Model description
Datum diameter = 106.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 28.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 124.0 mm
Price
Model
SPB 112
Model description
Datum diameter = 112.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 67.0 mm
5 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 118
Model description
Datum diameter = 118.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 125
Model description
Datum diameter = 125.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 132
Model description
Datum diameter = 132.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 140
Model description
Datum diameter = 140.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 30.0 mm ,Hub length l = 41.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 60.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 55.0 mm
4 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 150
Model description
Datum diameter = 150.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 48.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 160
Model description
"Datum diameter = 160.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 48.0 mm
3 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 170
Model description
"Datum diameter = 170.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 48.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 180
Model description
Datum diameter = 180.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 32.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 48.0 mm
3 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 190
Model description
Datum diameter = 190.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 48.0 mm
3 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 85.0 mm
Price
Model
SPB 200
Model description
Datum diameter = 200.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 38.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 48.0 mm
3 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 60.0 mm
5 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 212
Model description
Datum diameter = 212.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 48.0 mm
3 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 225
Model description
Datum diameter = 225.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 48.0 mm
3 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 90.0 mm
6 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 250
Model description
Datum diameter = 250.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 42.0 mm ,Hub length l = 43.0 mm
2 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 55.0 mm
3 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 280
Model description
Datum diameter = 280.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 49.0 mm
2 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 55.0 mm
3 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 300
Model description
Datum diameter = 300.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 49.0 mm
2 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 55.0 mm
3 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 60.0 mm
4 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 70.0 mm
5 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 315
Model description
Datum diameter = 315.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 49.0 mm
2 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 55.0 mm
3 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 67.0 mm
4 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 80.0 mm
5 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 355
Model description
Datum diameter = 355.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 48.0 mm ,Hub length l = 49.0 mm
2 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 55.0 mm
3 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 67.0 mm
4 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 80.0 mm
5 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 75.0 mm
6 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 400
Model description
Datum diameter = 400.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 49.0 mm
2 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 55.0 mm
3 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 67.0 mm
4 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 80.0 mm
5 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 85.0 mm
6 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 450
Model description
Datum diameter = 450.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 55.0 mm
2 groove , Finished bore hole dmax. = 55.0 mm ,Hub length l = 55.0 mm
3 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 67.0 mm
4 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 80.0 mm
5 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 500
Model description
Datum diameter = 500.00 mm
No. of grooves : 1 groove , Finished bore hole dmax. = 50.0 mm ,Hub length l = 55.0 mm
2 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 59.0 mm
3 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 67.0 mm
4 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 80.0 mm
5 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 560
Model description
Datum diameter = 560.00 mm
No. of grooves : 2 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 55.0 mm
3 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 67.0 mm
4 groove , Finished bore hole dmax. = 70.0 mm ,Hub length l = 80.0 mm
5 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 80.0 mm
6 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 90.0 mm
Price
Model
SPB 630
Model description
Datum diameter = 630.00 mm
No. of grooves : 2 groove , Finished bore hole dmax. = 60.0 mm ,Hub length l = 80.0 mm
3 groove , Finished bore hole dmax. = 65.0 mm ,Hub length l = 80.0 mm
4 groove , Finished bore hole dmax. = 75.0 mm ,Hub length l = 86.0 mm
5 groove , Finished bore hole dmax. = 80.0 mm ,Hub length l = 90.0 mm
6 groove , Finished bore hole dmax. = 90.0 mm ,Hub length l = 100.0 mm
Price
บริษัท ทีพีเอส แบริ่ง แอนด์ โซลูชั่นส์ จำกัด
98/8-9 หมู่ที่ 3 ตำบลดอนหัวฬ่อ อำเภอเมือง จังหวัดชลบุรี 20000
Copyright © 2021 TPS BEARING SOLUTION CO.,LTD All right served.Reserved. Web design by 1001click.
สอบถามเพิ่มเติม
