PRODUCT
![]()
ชื่อรุ่น :
MPR - 1.5 kW
แบรนด์
HASCON
รายละเอียด :
ดูรูปสินค้าเพิ่มเติมติดต่อเราได้ที่ :
Model
Model description
Price
Model
MPR 28B - 90 B5/B14
Model description
Rated power (P1n) = 1.5 kW
Output speed (n2) = 112-181 r/min
Output torque (M2n) = 73-117 Nm
Gear unit actual ratio (ia) = 7.73-12.47
Service factor (Fs) = 1.1
Dimension : DE8 = 24 mm , b = 8 mm , t = 27.3 mm , P = 140-200 mm , M = 115-165 mm
Price
Model
MPR 38B - 90 B5/B14
Model description
Rated power (P1n) = 1.5 kW
Output speed (n2) = 57-184 r/min
Output torque (M2n) = 72-230 Nm
Gear unit actual ratio (ia) = 7.60-24.44
Service factor (Fs) = 0.8-1.5
Dimension : DE8 = 24 mm , b = 8 mm , t = 27.3 mm , P = 120-200 mm , M = 115-165 mm
Price
Model
MPR 48B - 90 B5/B14
Model description
Rated power (P1n) = 1.5 kW
Output speed (n2) = 29-187 r/min
Output torque (M2n) = 70-454 Nm
Gear unit actual ratio (ia) = 7.48-48.18
Service factor (Fs) = 0.77-2.8
Dimension : DE8 = 19 mm , b = 6 mm , t = 21.8 mm , P = 120-200 mm , M = 100-165 mm
Price
Model
MPR 48B - 100 B5/B14
Model description
Rated power (P1n) = 1.5 kW
Output speed (n2) = 45-120 r/min
Output torque (M2n) = 110-291 Nm
Gear unit actual ratio (ia) = 7.48-19.84
Service factor (Fs) = 0.83-1.8
Dimension : DE8 = 28 mm , b = 8 mm , t = 31.3 mm , P = 160 mm , M = 130 mm
Price
Model
MPR 58B - 90 B5/B14
Model description
Rated power (P1n) = 1.5 kW
Output speed (n2) = 24-187 r/min
Output torque (M2n) = 70-556 Nm
Gear unit actual ratio (ia) = 7.48-59.04
Service factor (Fs) = 0.90-4.3
Dimension : DE8 = 24 mm , b = 8 mm , t = 27.3 mm , P = 200 mm , M = 165 mm
Price
Model
MPR 58B - 100 B5/B14
Model description
Rated power (P1n) = 1.5 kW
Output speed (n2) = 30-120 r/min
Output torque (M2n) = 110-443 Nm
Gear unit actual ratio (ia) = 7.48-30.24
Service factor (Fs) = 1.1-2.7
Dimension : DE8 = 28 mm , b = 8 mm , t = 31.3 mm , P = 160 mm , M = 130 mm
Price
Model
MPR 68B - 90 B5/B14
Model description
Rated power (P1n) = 1.5 kW
Output speed (n2) = 24-93 r/min
Output torque (M2n) = 142-557 Nm
Gear unit actual ratio (ia) = 15.11-59.22
Service factor (Fs) = 1.3-3.7
Dimension : DE8 = 24 mm , b = 8 mm , t = 27.3 mm , P = 200 mm , M = 165 mm
Price
Model
MPR 68B - 100 B5/B14
Model description
Rated power (P1n) = 1.5 kW
Output speed (n2) = 15.2-120 r/min
Output torque (M2n) = 110-867 Nm
Gear unit actual ratio (ia) = 7.49-59.22
Service factor (Fs) = 0.86-4.7
Dimension : DE8 = 28 mm , b = 8 mm , t = 31.3 mm , P = 160 mm , M = 130 mm
Price
