PRODUCT
![]()
ชื่อรุ่น :
XL 037
แบรนด์
SKF
รายละเอียด :
- ระยะห่างระหว่างฟัน ( Pitch ) = 5.08 mm (1/5")
- สายพานหน้ากว้าง 6.4 mm และ 9.5 mm
ดูรูปสินค้าเพิ่มเติมติดต่อเราได้ที่ :
Model
Model description
Price
Model
PHP 10XL037RSB
Model description
No. Teeth = 10
DIMENSIONS : Diameter (P.D.) = 16.17 mm , Pulley Type = 1F , Bore min = 5 mm , Bore max = 5 mm ,F = 14.3 mm , L = 19.8 mm , H = 9.5 mm
Price
Model
PHP 11XL037RSB
Model description
No. Teeth = 11
DIMENSIONS : Diameter (P.D.) = 17.79 mm , Pulley Type = 1F , Bore min = 5 mm , Bore max = 5 mm ,F = 14.3 mm , L = 19.8 mm , H = 9.5 mm
Price
Model
PHP 12XL037RSB
Model description
No. Teeth = 12
DIMENSIONS : Diameter (P.D.) = 19.40 mm , Pulley Type = 1F , Bore min = 5 mm , Bore max = 8 mm ,F = 14.3 mm , L = 19.8 mm , H = 12.7 mm
Price
Model
PHP 13XL037RSB
Model description
No. Teeth = 13
DIMENSIONS : Diameter (P.D.) = 21.02 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 8 mm ,F = 14.3 mm , L = 19.8 mm , H = 12.7 mm
Price
Model
PHP 14XL037RSB
Model description
No. Teeth = 14
DIMENSIONS : Diameter (P.D.) = 22.64 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 9 mm ,F = 14.3 mm , L = 19.8 mm , H = 14.3 mm
Price
Model
PHP 15XL037RSB
Model description
No. Teeth = 15
DIMENSIONS : Diameter (P.D.) = 24.26 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 11 mm ,F = 14.3 mm , L = 19.8 mm , H = 15.9 mm
Price
Model
PHP 16XL037RSB
Model description
No. Teeth = 16
DIMENSIONS : Diameter (P.D.) = 25.87 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 12 mm ,F = 14.3 mm , L = 19.8 mm , H = 17.5 mm
Price
Model
PHP 17XL037RSB
Model description
No. Teeth = 17
DIMENSIONS : Diameter (P.D.) = 27.49 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 13 mm ,F = 14.3 mm , L = 19.8 mm , H = 20.0 mm
Price
Model
PHP 18XL037RSB
Model description
No. Teeth = 18
DIMENSIONS : Diameter (P.D.) = 29.11 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 13 mm ,F = 14.3 mm , L = 19.8 mm , H = 20.6 mm
Price
Model
PHP 19XL037RSB
Model description
No. Teeth = 19
DIMENSIONS : Diameter (P.D.) = 30.72 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 13 mm ,F = 14.3 mm , L = 19.8 mm , H = 20.6 mm
Price
Model
PHP 20XL037RSB
Model description
No. Teeth = 20
DIMENSIONS : Diameter (P.D.) = 32.34 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 15 mm ,F = 14.3 mm , L = 22.2 mm , H = 23.8 mm
Price
Model
PHP 21XL037RSB
Model description
No. Teeth = 21
DIMENSIONS : Diameter (P.D.) = 33.96 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 15 mm ,F = 14.3 mm , L = 22.2 mm , H = 23.8 mm
Price
Model
PHP 22XL037RSB
Model description
No. Teeth = 22
DIMENSIONS : Diameter (P.D.) = 35.57 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 16 mm ,F = 14.3 mm , L = 22.2 mm , H = 25.4 mm
Price
Model
PHP 24XL037RSB
Model description
No. Teeth = 24
DIMENSIONS : Diameter (P.D.) = 38.81 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 18 mm ,F = 14.3 mm , L = 22.2 mm , H = 27.0 mm
Price
Model
PHP 26XL037RSB
Model description
No. Teeth = 26
DIMENSIONS : Diameter (P.D.) = 42.04 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 20 mm ,F = 14.3 mm , L = 22.2 mm , H = 30.0 mm
Price
Model
PHP 27XL037RSB
Model description
No. Teeth = 27
DIMENSIONS : Diameter (P.D.) = 43.66 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 20 mm ,F = 14.3 mm , L = 22.2 mm , H = 30.0 mm
Price
Model
PHP 28XL037RSB
Model description
No. Teeth = 28
DIMENSIONS : Diameter (P.D.) = 45.28 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 20 mm ,F = 14.3 mm , L = 22.2 mm , H = 30.2 mm
Price
Model
PHP 29XL037RSB
Model description
No. Teeth = 29
DIMENSIONS : Diameter (P.D.) = 46.89 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 20 mm ,F = 14.3 mm , L = 22.2 mm , H = 30.2 mm
Price
Model
PHP 30XL037RSB
Model description
No. Teeth = 30
DIMENSIONS : Diameter (P.D.) = 48.51 mm , Pulley Type = 1F , Bore min = 6 mm , Bore max = 24 mm ,F = 14.3 mm , L = 22.2 mm , H = 34.9 mm
Price
Model
PHP 32XL037RSB
Model description
No. Teeth = 32
DIMENSIONS : Diameter (P.D.) = 51.74 mm , Pulley Type = 1F , Bore min = 8 mm , Bore max = 25 mm ,F = 14.3 mm , L = 25.4 mm , H = 40 mm
Price
Model
PHP 34XL037RSB
Model description
No. Teeth = 34
DIMENSIONS : Diameter (P.D.) = 54.98 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 25 mm ,F = 14.3 mm , L = 25.4 mm , H = 38.0 mm
Price
Model
PHP 35XL037RSB
Model description
No. Teeth = 35
DIMENSIONS : Diameter (P.D.) = 56.60 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 25 mm ,F = 14.3 mm , L = 25.4 mm , H = 38.0 mm
Price
Model
PHP 36XL037RSB
Model description
No. Teeth = 36
DIMENSIONS : Diameter (P.D.) = 58.21 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm , H = 45.0 mm
Price
Model
PHP 38XL037RSB
Model description
No. Teeth = 38
DIMENSIONS : Diameter (P.D.) = 61.45 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm, H = 45.0 mm
Price
Model
PHP 40XL037RSB
Model description
No. Teeth = 40
DIMENSIONS : Diameter (P.D.) = 64.68 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm, H = 45.0 mm
Price
Model
PHP 42XL037RSB
Model description
No. Teeth = 42
DIMENSIONS : Diameter (P.D.) = 67,91 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm, H = 45.0 mm
Price
Model
PHP 44XL037RSB
Model description
No. Teeth = 44
DIMENSIONS : Diameter (P.D.) = 71,15 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm, H = 45.0 mm
Price
Model
PHP 45XL037RSB
Model description
No. Teeth = 45
DIMENSIONS : Diameter (P.D.) = 72.77 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm, H = 45.0 mm
Price
Model
PHP 48XL037RSB
Model description
No. Teeth = 48
DIMENSIONS : Diameter (P.D.) = 77.12 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm, H = 45.0 mm
Price
Model
PHP 60XL037RSB
Model description
No. Teeth = 60
DIMENSIONS : Diameter (P.D.) = 92.02 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm, H = 45.0 mm
Price
Model
PHP 72XL037RSB
Model description
No. Teeth = 72
DIMENSIONS : Diameter (P.D.) = 116.43 mm , Pulley Type = 1 , Bore min = 8 mm , Bore max = 30 mm ,F = 14.3 mm , L = 25.4 mm, H = 45.0 mm
Price
