PHF XXX

Bore range for min = 9.53 mm
DIMENSIONS : A = 0.31 in , B = 1.38 in , D = 2.00 in , E =1.00 in , F = 0.56 in

Bore range for min = 12.70 mm
DIMENSIONS : A = 0.43 in , B = 1.88 in , D = 2.63 in , E = 1.31 in , F = 0.81 in

Bore range for min = 12.70 mm
DIMENSIONS : A = 0.43 in , B = 2.18 in , D = 3.18 in , E = 1.31 in , F = 0.75 in

Bore range for min = 12.70 mm
DIMENSIONS : A = 0.43 in , B = 2.18 in , D = 3.18 in , E =1.81 in , F = 1.25 in

Bore range for min = 12.70 mm
DIMENSIONS : A = 0.56 in , B = 2.81 in , D = 3.88 in , E =1.93 in , F = 1.25 in

Bore range for min = 1/2 in
DIMENSIONS : A = 0.63 in , B = 3.13 in , D = 4.63 in , E = 2.06 in , F = 1.25 in

Bore range for min = 7/8 in
DIMENSIONS : A = 0.88 in , B = 3.83 in , D = 6.00 in , E =2.75 in , F = 1.63 in

Bore range for min = 1 in
DIMENSIONS : A = 1.00 in , B = 4.43 in , D = 6.63 in , E = 3.75 in , F = 2.50 in

Bore range for min = 1 7/16 in
DIMENSIONS : A = 1.13 in , B = 5.14 in , D = 7.25 in , E = 4.63 in , F = 3.18 in

Bore range for min = 2 15/16 in
DIMENSIONS : A = 1.25 in , B = 6.50 in , D = 9.00 in , E = 6.75 in , F = 5.18 in

Bore range for min = 2 7/16 in
DIMENSIONS : A = 1.50 in , B = 7.00 in , D = 10.00 in , E = 8.12 in , F = 6.25 in

Bore range for min = 2 15/18 in
DIMENSIONS : A = 1.75 in , B = 8.25 in , D = 11.75 in , E = 9.38 in , F = 7.25 in

Bore range for min = 4 in
DIMENSIONS : A = 2.00 in , B = 10.42 in , D = 15.00 in , E = 11.38 in , F = 9.00 in

Bore range for min = 6 in
DIMENSIONS : A = 2.75 in , B = 12.13 in , D = 17.75 in , E = 15.25 in , F = 12.00 in
