Dimensions Associated inner rings 1) Associated radial shaft seals 2)
IR series LR series Single lip Double lip
F w r
min
mm – –

35 0,8 – LR 30x35x12 5 G 35x42x4 SD 35x42x4
0,8 IR 30x35x17 LR 30x35x16 5 G 35x42x4 SD 35x42x4
0,8 IR 30x35x20 5 LR 30x35x20 5 – –

0,8 IR 30x35x20 5 LR 30x35x20 5 G 35x42x4 SD 35x42x4

40 0,8 – LR 35x40x12 5 G 40x47x4 SD 40x47x4
0,8 IR 35x40x20 LR 35x40x16 5 – –
0,8 IR 35x40x20 LR 35x40x16 5 G 40x47x4 SD 40x47x4 7.2

0,8 IR 35x40x20 5 LR 35x40x20 5 – –
0,8 IR 35x40x20 5 LR 35x40x20 5 G 40x47x4 SD 40x47x4

45 0,8 – – G 45x52x4 SD 45x52x4
0,8 IR 40x45x17 LR 40x45x16 5 G 45x52x4 SD 45x52x4
0,8 IR 40x45x20 5 LR 40x45x20 5 – –

0,8 IR 40x45x20 5 – G 45x52x4 SD 45x52x4

50 0,8 – LR 45x50x20 5 G 50x58x4 SD 50x58x4
0,8 IR 45x50x25 5 LR 45x50x25 5 – –
0,8 IR 45x50x25 5 LR 45x50x25 5 G 50x58x4 SD 50x58x4

55 0,8 – LR 50x55x20 5 G 55x63x5 –
0,8 – – G 55x63x5 –

60 0,8 – – – –
0,8 – – – –
0,8 – – – –

1) For additional information → Needle roller bearing inner rings, page 593
2) For additional information → skf com/seals

Product data online † skf.com/go/17000-7-2 623
