Mounting
Appropriate bearing Mounting bearings
housings with a tapered bore

Appropriate SKF bearing housings are avail- Bearings with a tapered bore are mounted
able in a variety of designs and sizes for a with an interference it, by using one of the
wide range of applications The designs following methods:
include:
1 Feeling the clearance reduction by
• SNL, SE plummer (pillow) block housings turning and swivelling the outer ring
in the 2, 3, 5 and 6 series (ig. 14)
• FNL langed housings – This method is valid for bearings with
• SAF plummer (pillow) block housings for Normal radial clearance (not for sealed
inch shafts bearings)
– The clearance reduction in the bearing 4
Additional information about SKF bearing is suficient when the outer ring can be
housings is available online at turned easily, but a slight resistance is
skf com/housings felt when it is swivelled out

2 Measuring the lock nut tightening angle
(table 7, page 448)
Mounting 3 Measuring the axial drive-up (table 7)

Mounting bearings 4 Applying the SKF Drive-up Method
For bearings with d ≥ 50 mm, SKF recom-
with a cylindrical mends using the SKF Drive-up Method
bore This is a fast, reliable and safe method to
determine the appropriate interference it
Additional information is available online
Refer to Mounting bearings with a cylindrical at skf com/drive-up
bore, page 201
For additional information about these
mounting methods, refer to Mounting bear-
ings with a tapered bore, page 203, or the
SKF bearing maintenance handbook

Fig. 12 Fig. 13 Fig. 14
Bearing with a tapered bore mounted with Sealed bearing with a tapered bore Check clearance reduction
a withdrawal sleeve on a stepped shaft mounted with an E design adapter sleeve

447
