Ordering information
Accessories Ordering information
The following accessories are available for SKF housings for paper machines are supplied
housings for paper machines: complete with covers, seals and plugs. The
bearings must be ordered separately.
• central lubrication systems, e.g. SKF
Flowline Order example
• condition monitoring sensors Two housings with inch thread dimensions
are required for a felt roll assembly – one for
For additional information, contact SKF. a 22218 EK/C3 spherical roller bearing in
the locating bearing position, and one for a
C 22218 K/C3 CARB toroidal roller bearing in
the non-locating bearing position at the end of
a shaft. The following items should be ordered
(in addition to the bearings):
• 1 SBFN 2218 BFN9
• 1 SBFN 2218 ARAN9
Two housings are required for a drying cylin-
der assembly – one for a 23144 CCK/C4W33
spherical roller bearing in the locating bearing
position, and one for a C 3144 K/C4 CARB
toroidal roller bearing in the non-locating
bearing position at the end of a shaft. The
housings require a special paint that can
accommodate special customer requirements.
The following items should be ordered (in
addition to the bearings):
• 1 SBPN 3144 BF/P..
• 1 SBPN 3144 ARA/P..
Two housings are required for a Yankee cylin-
der – one for a 230/670 CAK/C084W33
spherical roller bearing in the locating bearing
position, and one for a C 30/670 KM/C084
CARB toroidal roller bearing in the non-locat-
ing bearing position. The following items 13
should be ordered (in addition to the bearings):
• 1 SDM 30/670 F
• 1 SDM 30/670 RA
605
