Shaft Appropriate parts Mass
diameter Housing Bearings in the Bearing in the Shaft Shaft keys Shaft only
locating position non-locating to ISO 773
position
d a
mm – kg
75 PDR 315 NU 315 ECP + 6315/C3 NU 315 ECP VJ-PDRJ 315 18x11x100 29
80 PDR 316 NU 316 ECP + 6316/C3 NU 316 ECP VJ-PDRJ 316 20x12x100 34
85 PDR 317 NU 317 ECP + 6317/C3 NU 317 ECP VJ-PDRJ 317 20x12x100 42
90 PDR 318 NU 318 ECP + 6318/C3 NU 318 ECP VJ-PDRJ 318 22x14x140 50,5
95 PDR 319 NU 319 ECP + 6319/C3 NU 319 ECP VJ-PDRJ 319 22x14x140 58
100 PDR 320 NU 320 ECP + 6320/C3 NU 320 ECP VJ-PDRJ 320 25x14x140 67
110 PDR 322 NU 322 ECP + 6322/C3 NU 322 ECP VJ-PDRJ 322 28x16x180 86,5
120 PDR 324 NU 324 ECP + 6324/C3 NU 324 ECP VJ-PDRJ 324 28x16x180 104
12.7

587
