Page 377 - SKF-bearing-housings
P. 377
G 1) J 1 A 1
N 1
N
H 2
J
L
7.1
Shaft Dimensions Eye bolt Mass
diam- Housing according Housing
eter to DIN 580
H J L N S
d a A B d 1 B 1 C a D a b a s 2 H 0 H 1 H 2 J 1 N 1
mm mm – kg
160 360 205 137 114 320 78 53,5 455 545 245 75 545 150 650 42 35 180 M 24 213
170 370 220 139 120 340 82 52,5 480 570 260 85 590 150 720 50 42 185 M 24 249
180 378 227 140 126 360 86 51 510 600 275 85 600 160 730 50 42 189 M 24 273
200 404 255 148 136 400 95 50 565 674 305 95 670 180 820 50 42 202 M 24 361
220 420 270 150 148 440 105 45,5 625 734 340 100 740 190 900 50 42 210 M 24 456
1) For sizes and tightening torques of the attachment bolts refer to table 3 on page 363.
