Ordering information

Supporting the housing Fig. 10
A stop should be used to accommodate loads Position 2
acting parallel to the support surface. The stop Position 1 + 2
also makes alignment during mounting easier.

Eye bolts Position 3
All separate components are prepared for lift-
ing. There is an integral flange on the cap with
two cast holes. The housing base can be lifted
with eye bolts inserted into the threaded holes
for the cap bolts. Position 2
Various threaded holes in the covers can be
used for inserting eye bolts. 6

Condition monitoring
SED housings have a drilled and tapped hole
at the integral flange on the cap specially
designed for the SKF wireless vibration sensor,
1)
CMWA 8800 .
The CMWA 8800 Wireless Condition
Monitoring Node is a combined sensor and
wireless communication node that measures Ordering information
both vibration and temperature. The device
uses the WirelessHART communication proto- SED housings are supplied with the appropriate
col, which offers a simple, reliable and secure covers, multi-seals and a wireless condition
means of transmitting machine vibration and monitoring sensor. Bearings and adapter
temperature data wirelessly back to a host sleeves must be ordered separately.
computer network.
SED housings also have additional positions Order example
for other sensors († fig. 10). Two plummer block housings are required for
Position 1 is a measurement point per- two 230/560 CAK/W33 spherical roller bear-
pendicular to the shaft appropriate for tem- ings on OH 30/560 H adapter sleeves. One
perature sensors. housing will accommodate the non-locating
Position 2 is a measurement point per- bearing at the end of the shaft. The other
pendicular or parallel to the shaft appropriate housing will accommodate the locating bear-
for vibration sensors. ing and a through shaft.
Position 3 is a drilled hole for lubrication The following items should be ordered:
perpendicular to the shaft that can be used for
both temperature and vibration sensors. • 1 housing SED 30/560 BF
• 1 housing SED 30/560 AL
Accessories

There are several accessories available for SED
housings, including centralized lubrication
systems and condition monitoring sensors.
For additional information, refer to SKF tools
and products († page 47).
1) Check availability before ordering.
