Designs and variants
Needle roller and Double direction Needle roller thrust
cage thrust bearings bearings with a

assemblies centring lange
Double direction bearings:
AXK series needle roller and cage thrust AXW series needle roller thrust bearings
assemblies (ig. 1): • can accommodate axial loads in both with a centring lange (ig. 2 and ig. 5):
directions
• are available for 4 ≤ d ≤ 160 mm • can be created by combining two needle • are available for 10 ≤ d ≤ 50 mm
• can accommodate axial loads in one roller and cage thrust assemblies and two • accommodate axial loads in one direction
direction only bearing washers with an intermediate only
• can be combined with washers in the LS, washer • consist of a needle roller and cage thrust
AS, GS 811 or WS 811 series (Bearing Depending on the design, an inter- assembly and a thrust washer with a
washers, page 898) in applications where mediate washer can be shaft or housing centring lange
adjacent components cannot serve as centred (ig. 3 and ig. 4) The lange facilitates mounting and
raceways accurately centres the housing washer
Intermediate washers must have the same radially (ig. 6 and ig. 7)
hardness and surface inish as bearing
washers SKF does not supply intermediate
washers, but provides material speciications Combined needle roller
and dimensional data on request bearing arrangements
For additional information, refer to Design
considerations, page 903 To accommodate combined radial and axial
loads, needle roller thrust bearings in the
AXW series can be combined with the
following radial needle roller bearings:
• drawn cup needle roller bearings with a
closed end or with open ends (ig. 6)
• needle roller bearings with machined
Fig. 3 Fig. 5 rings (ig. 7)
Double direction bearing, shaft centred AXW needle roller thrust bearing with a
centring lange These arrangements provide a cost-
effective and compact solution for combined
Intermediate washer
loads

Fig. 7
AXW series bearing combined with a
needle roller bearing with machined rings

Fig. 4 Fig. 6
Double direction bearing, housing centred AXW series bearing combined with a
drawn cup needle roller bearing

Intermediate washer

12

Without an With an
inner ring inner ring

897
