12 Needle roller thrust bearings
Bearing washers 811 series shaft (preix WS) and Fig. 8
housing washers (preix GS)
LS series universal washer
Bearing washers are required in applications
where adjacent machine components cannot • are used primarily with cylindrical roller
serve as raceways and cage thrust assemblies
Appropriate washers are listed in the • can also be combined with needle roller
product tables, page 906 and must be and cage thrust assemblies
ordered separately, because of the number • can be used in high-speed applications
of possible combinations where accurate centring of the bearing
The following series can be combined with washers is required
needle roller thrust bearings:
For additional information about 811 series
LS series universal washers washers, refer to Cylindrical roller thrust
bearings, page 877
(ig. 8)
Fig. 9
• are made of hardened carbon chromium AS series thin universal washer
bearing steel
• can be used as shaft or housing washers Cages
for needle roller thrust bearings in the AXK
series SKF needle roller thrust bearings are itted
• can be used as shaft washers for bearings with one of the cages shown in table 1
in the AXW series Bearings in the AXW series are itted exclu-
• are available for 6 ≤ d ≤ 160 mm sively with steel cages
• raceway surface is ground, while all other When used at high temperatures, some
surfaces are turned lubricants can have a detrimental effect on
• are used for applications where accurate polyamide cages For additional information
centring of the washers is not necessary about the suitability of cages, refer to Cages,
or where low speeds are involved page 187
• washer face opposite the side with the
chamfers is the raceway surface and
should face the rollers

AS series thin universal washers
(ig. 9)

• are 1 mm thick
• are made of spring steel and hardened
• can be used as shaft or housing washers
for needle roller thrust bearings in the AXK
series
• can be used as shaft washers for bearings
in the AXW series
• are available for 4 ≤ d ≤ 160 mm
• can be used to provide a cost-effective
bearing solution, if adjacent machine
components are not hardened, but have
adequate stiffness and the requirements
to geometrical tolerances are moderate

12 Both faces of the washers are polished and
can be used as raceways
