Split pillow blocks SAF and SAW series

Seal chart for SAF and SAW housings

Shaft d a d a d a d b d c d b d c Labyrinth seal 1)
diameter 0(00) 5(00) 6(00) 2(00) 2(00) 3(00) 3(00) Ring seal O-ring for LOR 2)
Series Series Series Series Series Series Series
in. –
2 15 /16 517* 213 216 313 LOR-53 AS-568-141
2 15 /16 316 LOR-59 AS-568-151
3 617 LOR-185 AS-568-151
3 517 213 216* 313 LOR-54 AS-568-041
3 316* LOR-60 AS-568-151
3 1 /16 518 618 317 LOR-186 38309-186
3 1 /16 213* 216 313* LOR-55 38309-55
3 1 /16 217 LOR-61 38309-61
3 1 /8 518 618 317 LOR-187 AS-568-152
3 1 /8 213 216 313 LOR-56 AS-568-042
3 1 /8 217 314 LOR-62 AS-568-042
3 3 /16 518* 618* 317* LOR-188 AS-568-152
3 3 /16 217* 314 LOR-63 AS-568-042
3 1 /4 518 618 317 LOR-189 AS-568-152
3 1 /4 217 314* LOR-64 AS-568-042
3 5 /16 520 620 220 LOR-100 38309-100
3 5 /16 217 LOR-65 38309-65
3 5 /16 218 318 LOR-190 38309-190
3 3 /8 215/216 315 LOR-78 AS-568-043
3 3 /8 217 LOR-66 AS-568-043
3 3 /8 520 620 220 LOR-101 AS-568-153
3 3 /8 218* 318* LOR-191 AS-568-153
3 7 /16 215*/216 315* LOR-79 AS-568-043
3 7 /16 520* 620* 220 LOR-102 AS-568-153
3 1 /2 215/216 315 LOR-80 AS-568-043
3 1 /2 520 620 220 LOR-103 AS-568-153
3 9 /16 215/216 315 LOR-81 38309-81
3 9 /16 316 LOR-83 38309-83
3 5 /8 215/216* 315 LOR-82 AS-568-044
3 5 /8 316* LOR-84 AS-568-154
3 11 /16 316 LOR-85 AS-568-154
3 11 /16 320 LOR-104 AS-568-154
3 3 /4 316 LOR-86 AS-568-154
3 3 /4 320 LOR-105 AS-568-154
3 13 /16 316 LOR-87 38309-87
3 13 /16 320* 220* LOR-106 38309-106
3 13 /16 522 622 317 LOR-107 38309-107
3 7 /8 522 622 317 LOR-108 AS-568-155
3 7 /8 217 LOR-88 AS-568-045
3 15 /16 522* 622* 317* LOR-109 AS-568-155
3 15 /16 217* LOR-89 AS-568-045
4 522 622 317 LOR-110 AS-568-155
The table continues on next spread.

* = Standard shaft diameter, all others are optional shaft diameters
1) Speed rating is the same as bearing speed rating
2) O-ring supplied with LOR is for replacement only, AS-568-### are industry standard O-rings available at most SKF authorized
distributors
