Page 313 - SKF-bearing-housings

N
N 1

G J 1
5.3
H 2

J
L

Shaft Dimensions Eye bolt Mass
diameter Housings according to Housing
DIN 580
A H J L N s G
d a d b A 1 C a D a H 1 H 2 J 1 N 1
mm mm – kg
220 240 280 230 130 340 411 210 85 510 130 610 42 35 10 30 M 20 123

240 290 240 140 370 434 220 90 540 140 640 42 35 12 30 M 20 138

240 310 260 164 400 474 240 95 600 150 700 42 35 12 30 M 24 187
240 310 260 148 400 474 240 95 600 150 700 42 35 12 30 M 24 187

240 320 280 166 460 550 280 105 670 160 790 50 42 16 36 M 24 252
