Page 641 - SKF-bearing-housings

J 1
G
N

H 2
J
L

Shaft Dimensions Axial Dimensions Mass
diameter Housing displace- Shaft abutment and fillet Housing
ment
J L G N s
d a J 1 d b d c a 1 a 2 a 3 a 5 r 1
mm mm mm mm kg
1) 1)
1 060 2 000 460 2 450 M 100 110 – 1 110 1 055 237,5 470 475 15
2 000 460 2 450 M 100 110 ±75 1 110 1 060 167,5 420 – 1) 6 1)
2 000 460 2 450 M 100 110 ±75 1 110 1 060 167,5 420 – 1) 6 1)
1 120 2 150 460 2 560 M 100 110 – 1 195 1 115 237,5 470 475 480 15 7 500
2 150 460 2 560 M 100 110 ±75 1 195 1 120 167,5 420 – 480 6 7 400
2 150 460 2 560 M 100 110 ±70 1 195 1 120 167,5 420 – 480 6 7 100
1 180 2 300 480 2 750 M 110 120 – 1 230 1 175 250 495 500 500 15 8 700
2 300 480 2 750 M 110 120 ±80 1 230 1 180 177,5 430 – 500 6 8 500
2 300 480 2 750 M 110 120 ±70 1 230 1 180 177,5 430 – 500 6 8 200

14.1

1) Contact SKF for missing values.
