Split pillow blocks SAF and SAW series

Oil level for SAF housings

Oil level 1) Housing series
13(00) 15(00) 16(00) 222(00) 223(00) 225(00) 226(00)
in. –
1507 22507
7 /8
22509
31 /32
1 1509

1 3 /32 22510, 22513
1 1 /8 1510 22515
1 3 /16 1513 22511

1 7 /32 1308
1 1 /4 1511, 1515 22216 22516
1 9 /32 22309 22609

1 5 /16 1309 1516 1609 22312
1 13 /32 22313 22613
1 3 /8 1312 22217 22310 22517 22610

1 7 /16 1310, 1313 1517 1610, 1613 22311 22611
1 15 /32 22314
1 1 /2 1311 1518 1611 22218 22518

1 9 /16 1314
1 19 /32 22315 22615
1 21 /32 1520 22220 22520

1 11 /16 1315 1615 22316 22616
1 23 /32
1 3 /4 22317 22617

1 25 /32 1522 22222 22520
1 13 /16 1316 1616 22308
1 27 /32 22224 22524

1 7 /8 1317 1617 22318 22618
1 15 /16
2 1318 1618 22230 22530

2 1 /32 22228 22320 22528 22620
2 1 /16 22232 22532
2 5 /32 22234 22534

2 3 /16 1320 1620
2 7 /32
2 1 /4

2 11 /32 22226 22526
2 3 /8 22236 22324 22536 22624
2 13 /32 22322 22622

2 7 /16 22238 22326 22538 22626
2 15 /32 22240 22540
2 1 /2 1322 1622

2 9 /16 22328 22628
2 5 /8 22330 22630
2 11 /16 22332 22632

2 3 /4 22334 22634
2 7 /8
3 1 /8 22244 22544

3 3 /8 22338 22638
3 7 /16 22340 22640
1) The oil level is measured from the base of the housing. Mark the min. and max. level on the oil level gauge.
