N
N 1

G J 1
5.2
H 2

J
L

Shaft Dimensions Eye bolt Mass
diameter according to Housing
DIN 580
A H J L N s G G
d a A 1 C a D a H 1 H 2 J 1 N 1
in./mm mm in. – kg

7 15 /16 280 230 130 340 411 210 85 510 130 610 42 35 10 30 1 1 /4 M 20 123
201,613
290 240 140 370 434 220 90 540 140 640 42 35 12 30 1 1 /4 M 20 138

310 260 148 400 474 240 95 600 150 700 42 35 12 30 1 1 /4 M 24 187

310 260 164 400 474 240 95 600 150 700 42 25 12 30 1 1 /4 M 24 187

320 280 166 460 550 280 105 670 160 790 50 42 16 36 1 1 /2 M 24 252
8 280 230 130 340 411 210 85 510 130 610 42 35 10 30 1 1 /4 M 20 123
203,2
310 260 148 400 474 240 95 600 150 700 42 35 12 30 1 1 /4 M 24 187

8 7 /16 290 240 140 360 434 220 90 540 140 640 42 35 12 30 1 1 /4 M 20 139
214,312

320 280 164 440 516 260 100 650 160 770 50 42 13 36 1 1 /2 M 24 221

279
