Mounting
Mounting • SKF recommends positioning the lubrica-
tion hole in the stud head in the unloaded
zone of the cam follower The position of
Cam followers can be attached to associated this hole corresponds to the SKF trade-
components (ig. 13) using the hexagonal mark on the head end of the stud
nut (table 3, page 970) supplied with the • The lubrication hole in position 3 that is
cam follower Spring washers, which are not parallel and in line with the lubrication
supplied by SKF, serve to secure the nuts hole in the stud head (ig. 12, page 971)
may be used to incorporate a locking
• To exploit the full load carrying capacity of device to prevent the stud from turning
cam followers, the nuts should be tight- • When inserting a plug, it should be 16
ened to the recommended torque values pressed into place using a mandrel
(table 3) (ig. 14)
• Where heavy vibrations occur, cam follow-
ers can be located using:
– self-locking nuts in accordance with
ISO 10511
– special lock washers
For self-locking nuts, a higher tighten-
ing torque must be applied Follow the
recommendations of the nut
manufacturer
• Cam followers, sizes ≥ 22, have a hex-
agonal recess in the stud head and can be
held in place by a hexagonal key (Allen
wrench) while the nut is being tightened
• Some small cam follower designs (sizes 16
and 19) have a slot in the stud head
instead and can be held in place by a
screwdriver For additional information,
refer to the illustrations in the product
table, page 978
• Depending on the mounting conditions,
cam followers with an eccentric collar can
be adjusted to the required eccentricity via
the slot or the hexagonal recess
• Do not hit the head of the stud as damage
to the cam follower may result

Fig. 14
Inserting the VD1 plug with a mandrel

5,2

10 2,7
