Loads

Bearing data

Thrust ball bearings with lat housing washers Thrust ball bearings with sphered housing washers

Dimension ISO 104 ISO 20516
standards Bearings in the BA series are not standardized

Tolerances Normal Normal
P5 or P6 on request (single direction bearings only)

For additional
information Values: ISO 199 (table 10, page 46)
† page 35 Bearings in the BA series are not standardized

Permissible Cannot tolerate any misalignment Accommodate only initial misalignment
misalignment
5

Loads

Minimum load Symbols
q n ⎞ 2
F am = A ———– A minimum load factor (product tables, page 472)
⎝ 1 000 ⎠
For additional F a axial load [kN]
information F am minimum axial load [kN]
† page 106 n rotational speed [r/min]
P equivalent dynamic bearing load [kN]
Equivalent P = F a P 0 equivalent static bearing load [kN]
dynamic bearing
load
For additional
information
† page 91

Equivalent static P = F a
0
bearing load
For additional
information
† page 105
