Dimensions Mass Designations
Lock nut Associated
locking clip spanner eye bolt
G d 1 d 2 d 3 B B 5 b h

mm kg –

Tr 800x7 870 832 920 90 112 55 25 99,5 ▶ HM 30/800 MS 30/800-750 TMFN 600-750 M 12

Tr 850x7 925 887 980 90 115 60 25 115 ▶ HM 30/850 MS 30/900-850 – M 12

Tr 900x7 975 937 1 030 100 125 60 25 131 ▶ HM 30/900 MS 30/900-850 – M 16

Tr 950x8 1 025 985 1 080 100 125 60 25 139 ▶ HM 30/950 MS 30/950 – M 16

Tr 1000x8 1 085 1 040 1 140 100 125 60 25 157 ▶ HM 30/1000 MS 30/1000 – M 16

Tr 1060x8 1 145 1 100 1 200 100 125 60 25 166 ▶ HM 30/1060 MS 30/1000 – M 16

Tr 1120x8 1 205 1 160 1 260 100 125 60 25 175 ▶ HM 30/1120 MS 30/1000 – M 16

25.3

▶ Popular item

Product data online † skf.com/go/17000-25-3 1109
