Split pillow blocks

SAF and SAW series

(inch dimensions)

SAF and SAW split pillow (plummer) block
Bearing types housings are popular SKF bearing housings
• Spherical roller bearings (SAF and SAW) with inch dimensions, developed to be the first
• Self-aligning ball bearings (SAF) choice for design, quality and economy.
• CARB toroidal roller bearings (SAF)
SAF and SAW housings enable the incorpo-
rated bearings to achieve maximum service
Bearing dimension series life with less need for maintenance. Different
• 12, 13, 22, 23, 30 (SAF) housing variants and seal designs are available,
• 22, 32 (SAW)
making the use of tailored housings virtually 8
unnecessary and enabling cost-effective
Shaft diameter range bearing arrangements.
• 1 3 /16 to 10 1 /2 in. (SAF)
• 3 3 /16 to 7 15 /16 in. (SAW)
! Units of measurement
Typical shaft-bearing combinations In this chapter only imperial units
• Plain shaft with bearing on an adapter are used. To convert imperial units to
sleeve metric units, refer to the conversion table
• Stepped shaft with bearing on a cylin- on page 10.
drical seat

Seals
• Labyrinth
• Contact
• Heavy-duty

Lubrication
• Grease
• Oil
Materials
• Grey cast iron
• Cast steel
• Spheroidal graphite cast iron
Mounting
• Two-bolt mounting
• Four-bolt mounting
