Split plummer block housings SED 30, 31, 32 and 39 series

Housing material Housing variants
SED plummer block housings are made of
spheroidal graphite cast iron. In addition to standard design SED housings, a
number of variants are also available. Variants
Paint, corrosion protection include housings painted to other colours and
SED housings are painted black (RAL 9005) corrosivity categories, housings with a nar-
using a water based alkyd/acryl paint. The rower base and differently positioned attach-
paint protects the housing in accordance with ment bolt holes, housings suitable for bearings
ISO 12944-2, corrosivity category C3, i.e. on a cylindrical seat on stepped shafts, and
exterior atmospheres with a moderate level of housings modified for circulating oil
pollution; coastal areas with low salinity; inter- lubrication.
ior atmospheres with high humidity and some For additional information, contact the
air pollution († Environmental conditions, SKF application engineering service.
page 36). The paint is not affected by most
lubricating or engine oils, cutting fluids or
alkalescent washing chem icals. Housings can Housings for circulating oil lubrication
be repainted with most water or solvent based systems
1- or 2-com ponent paints. Housings modified for circulating oil lubrica-
Unpainted surfaces are protected by a sol- tion systems have a threaded oil outlet hole in
ventless rust inhibitor. each cover (designation suffix RT). The tapped
hole used for grease relubrication can be used
as the oil inlet.
Dimension standards
The dimensions of SED housings are not
standardized either nationally or
internationally.

336
