P. 1117
Dimensions Axial load Mass Designations Grub (set) screw
carrying Lock nut Associated Size Recommended
capacity spanner tightening
G d 1 d 3 d 4 d 5 B M b h static torque
mm kN kg – – Nm
M 120x2 144 155 122 142 32 – 10 4 860 1,6 ▶ KMT 24 HN 21-22 M 10 35
M 130x2 154 165 132 152 32 – 12 5 920 1,7 ▶ KMT 26 TMFN 23-30 M 10 35
M 140x2 164 175 142 162 32 – 14 5 980 1,8 ▶ KMT 28 TMFN 23-30 M 10 35
M 150x2 174 185 152 172 32 – 14 5 1 040 1,95 ▶ KMT 30 TMFN 23-30 M 10 35
M 160x3 184 195 162 182 32 – 14 5 1 100 2,1 ▶ KMT 32 TMFN 23-30 M 10 35
M 170x3 192 205 172 192 32 – 14 5 1 160 2,2 ▶ KMT 34 TMFN 30-40 M 10 35
M 180x3 204 215 182 202 32 – 16 5 1 220 2,3 ▶ KMT 36 TMFN 30-40 M 10 35
M 190x3 214 225 192 212 32 – 16 5 1 280 2,4 ▶ KMT 38 TMFN 30-40 M 10 35
M 200x3 224 235 202 222 32 – 18 5 1 340 2,5 ▶ KMT 40 TMFN 30-40 M 10 35
25.6
▶ Popular item
Product data online † skf.com/go/17000-25-6 1115
