18.1 Text index

vibration 196 cap bolts 362–363
withdrawal sleeve mounting 203 compared with other split housings 31
SNLN plummer block housings 151–187 condition monitoring 368–369
accessories 157, 178 contamination 365
adapter sleeve mounting 168–169, 180–183 corrosion protection 355
alignment 157 cylindrical seat mounting 356, 360, 378–381
attachment bolt holes 155–156, 158–159 design considerations 360–363
attachment bolt recommendations 171–172 designation systems 351–352
axial loads 171 designs and variants 353–356
axial shaft displacement 162–163, 166 dimension standards 355
bearing types and dimension series 151, 164 dimples 354
breaking loads 170–171 dowel pins and holes 354, 362, 368
cap bolts 171–172 eye bolts 354, 371–377
compared with other split housings 30 features and benefits 354–355
condition monitoring 157, 178 interchangeability 355
contamination 162–163, 164, 173 ISO standards 355, 363, 368–369
corrosion protection 158 load carrying capacity 361–362, 368
cylindrical seat mounting 168–169, 184–187 locating (stabilizing) rings 352, 360
design considerations 168–172 locating and non-locating bearing positions 360
designation systems 153–154 lubrication 356, 364–367
designs and variants 155–159 magnetic plugs 354, 365
dimension standards 158 markings 355, 364
dimples 157, 174–175, 177 materials 355–356, 357, 362
dowel pins and holes 157, 171, 177 misalignment 357
eye bolts 157 mounting 354, 368
grease escape holes 176 oil fills 364
grease fittings 153, 174–175 oil inlet holes 367
heat dissipation 156 oil level 356, 364–365, 367
initial grease fills 173 oil level gauges 352, 354, 362, 364–365
interchangeability 157, 158 oil outlet holes 365, 367
ISO standards 158, 172, 178 operating speed 362, 366
load carrying capacity 170–172, 177 operating temperature 354, 356, 357, 362
locating (stabilizing) rings 154, 168 ordering information 369
locating and non-locating bearing positions 168 paint specifications 355, 362
lubrication 173–176, 178 product tables 370–381
markings 157 sealing solutions 351, 356–359
materials 158, 162–163 shaft diameter range 349
misalignment 162–163, 166 shaft specifications 357, 362
mounting 157, 177 shaft-bearing combinations 360
operating speed 162–164, 166, 172, 173 start-up 364–365
operating temperature 162–164, 166, 172 stops 362, 368
ordering information 179 torque specifications 363
paint specifications 158, 172 spacer sleeves 26
plugs 174–175 axial location 42–43
product tables 180–187 spacing washers 534, 539
relubrication 156, 174–176 speed † operating speed
ribs 156 spherical roller bearings
seal groove dimensions 167 applicable housings 30–34
sealing solutions 154, 160–167, 176 in FNL flanged housings 539, 543, 546–551
shaft diameter range 151 in PD two-bearing housings 556, 562–563
shaft end lengths 165 in SAF pillow blocks 410, 414, 422–429, 436–443
shaft specifications 162–163, 165, 166 in SAW pillow blocks 410, 414, 422–429, 436–443
shaft-bearing combinations 168–169 in SBD plummer block housings 492, 498, 502–525
spacer sleeves 168 in SBFN felt roll housings 592, 598–599
splash plates 176 in SBPN drying cylinder housings 592, 598–599, 606–621
stiffness 156 in SDAF pillow blocks 468, 472–483
stops 171, 177 in SDM Yankee cylinder housings 592, 598–599, 606–621
support rings 161 in SKND converter trunnion housings 626–627, 634–637
torque specifications 171 in SNL 2, 3, 5 & 6 plummer block housings 80, 86–137
vertical shaft arrangements 161, 162–163 in SNLN plummer block housings 174, 180–187
vibration 158 in SONL plummer block housings 356, 367, 370–381
withdrawal sleeve mounting 168–169 in THD take-up housings 492, 498, 526–529
SOFN plummer block housings 31 in the SKF self-aligning bearing system 41
SONL plummer block housings 349–381 relubrication via the outer ring 46
accessories 369 suitability for SKF housings 40
adapter sleeve mounting (inch shafts) 356, 360, 362, spheroidal graphite cast iron (ductile iron)
374–377 applicable housings 30–32, 34
adapter sleeve mounting (metric shafts) 356, 360, 362, material properties 29
370–373 split housings 23
alignment 354 FSDR .. K mill trunnion housings 642
attachment bolt holes 353 housing selection 27, 30–31
attachment bolt recommendations 363 load carrying capacity 44
axial loads 362 SAF pillow blocks 386
axial shaft displacement 357 SAW pillow blocks 386
bearing types and dimension series 349 SDAF pillow blocks 452
breaking loads 361–362 SDM Yankee cylinder housings 592
