18.1 Text index

dismounting 145 support 339, 342
dowel pins and holes 82, 145 torque specifications 339, 340, 342
features and benefits 144–147 self-aligning ball bearings
grease escape holes 81, 147 applicable housings 30–34
grease fitting kits 145, 148 in FNL flanged housings 543, 546–551
grease guiding system 146 in SAF pillow blocks 410, 414, 418–421, 434–435
initial grease fills 78, 145–146 in SNL 2, 3, 5 & 6 plummer block housings 69, 80, 86–137
interchangeability 144, 148 in SONL plummer block housings 356, 367, 370–381
ISO standards 147, 148 suitability for SKF housings 40
locating (stabilizing) rings 142 self-aligning bearing system † SKF self-aligning bearing
lubrication 146 system
markings 144–146 sensor positions † condition monitoring
materials 148 serial numbers
mounting 145 on SAF pillow blocks 387
ordering information 149 on SAW pillow blocks 387
paint specifications 148 on SE plummer block housings 144
product tables 86–137 on SNL 2, 3, 5 & 6 plummer block housings 60–61
ribs 144 on SNL 30, 31 & 32 plummer block housings 194
safe loads 76 on SNLN plummer block housings 157
seal groove dimensions 68 on SONL plummer block housings 355
sealing solutions 142 set (grub) screws
shaft end lengths 69 in inch roller bearing units 696, 704, 707
stiffness 144 in metric roller bearing units 662–664, 672, 682
torque specifications 62, 77 shaft abutments 26
seal counterfaces accuracy requirements 45
accuracy requirements 45 shaft arrangements 25–26
repair possibilities 51 shaft diameter 24
seal grooves 25 per housing series 30–34
seal kits 351, 358–359 shaft displacement † axial shaft displacement
sealed bearings shaft roughness † surface roughness
in SAF pillow blocks 401, 408 shaft sleeves 26
in SAW pillow blocks 401, 408 for FSDR .. K mill trunnion housings 645
in SBD plummer block housings 492 for PD two-bearing housings 570
in SNL 2, 3, 5 & 6 plummer block housings 68, 78 for SONL plummer block housings 356–359, 360, 362, 364
in SNL 30, 31 & 32 plummer block housings 200, 213 in shaft-bearing combinations 42–43
in SNLN plummer block housings 164, 173 shaft-bearing combinations
in THD take-up housings 492 comparison table 42–43
in the SKF three-barrier solution 39 per housing series 30–34
sealing solutions 36–39 shafts 24
installation 51 specifications 45
per housing series 30–34 shims 50–51
SKF three-barrier solution 39 SKF ConCentra locking method
SED plummer block housings 331–347 for inch roller bearing units 696
accessories 343 for metric roller bearing units 663
alignment 334–335, 342 SKF ConCentra roller bearing units
applications 331 FYNT flanged units (metric) 662, 688–689
attachment bolt holes 334, 336 SYE .. N pillow block units (inch) 694, 708–715
attachment bolt recommendations 340–341 SYNT plummer block units (metric) 662, 686–687
compared with other split housings 31 SYR .. N pillow block units (inch) 694, 708–715
condition monitoring 343 SKF Flowline 48–49, 366
corrosion protection 336 SKF Housing Select 35
designation systems 333 SKF Multilube 48–49
designs and variants 334–336 SKF MultiPoint 47
dimension standards 336 SKF self-aligning bearing system 41
eye bolts and lifting holes 334–335, 342 and the SKF three-barrier solution 39
features and benefits 334–335 SKF SPEEDI-SLEEVE 51
grease/oil escape holes 334–335, 342 SKF SYSTEM 24 47
grease fittings 342 SKF three-barrier solution 39
initial grease fills 342 SKND converter trunnion housings 623–637
ISO standards 336, 339, 340, 342 accessories 632–633
load carrying capacity 338–339, 342 alignment 628
locating and non-locating bearing positions 338 attachment bolt holes 626
lubrication 342 axial loads 623, 632
materials 336, 337, 340 axial shaft displacement 630, 632
mounting 334, 342–343 bearing types and dimension series 623, 626
operating speed 337, 340 cap bolts 628
operating temperature 337, 340 compared with other application-specific housings 34
ordering information 343 condition monitoring 632–633
paint specifications 336, 340 contamination 628, 629, 631
product tables 344–347 corrosion protection 629
relubrication 337, 342 covers 626
sealing solutions 337 design considerations 630
shaft specifications 337 designation systems 625
shaft-bearing combinations 338 designs and variants 626–629
stiffness 334–335 features and benefits 628
stops 339, 342 grease sampling slots 631
