Sealing solutions

Table 2

Contact seal 3) Taconite seals End plug
Speed limit 4) with contact with V-Ring Speed limit 4)
seal 5) seal
– r/min – r/min –

B-10724-184 1 950 TER-57 TER-57 V 1 050 EPR-10
B-10724-184 1 950 TER-58 TER-58 V 1 050 EPR-10
B-10724-184 1 950 TER-59 TER-59 V 1 050 EPR-10
B-10724-184 1 950 TER-60 TER-60 V 1 050 EPR-10
– 6) TER-67 TER-67 V 950 EPR-11
B-10724-117 1 300 TER-119 TER-119 V 700 EPR-15
– 6) – TER-205 TER-205 V 675 –
B-10724-117 1 300 TER-119 TER-119 V 575 EPR-15
B-10724-122 1 150 TER-121 TER-121 V 625 –
B-10724-122 1 150 TER-122 TER-122 V 520 EPR-27
B-10724-125 1 075 TER-124 TER-124 V 590 EPR-16
B-10724-125 1 075 TER-125 TER-125 V 590 EPR-16
B-10724-125 1 075 TER-126 TER-126 V 590 EPR-16
B-10724-125 1 075 TER-127 TER-127 V 575 –
B-10724-125 1 075 TER-128 TER-128 V 575 EPR-16
B-10724-130 1 050 TER-129 TER-129 V 575 EPR-16
B-10724-130 1 050 TER-130 TER-130 V 560 EPR-16
B-10724-130 1 050 TER-131 TER-131 V 560 EPR-16
– 6) – TER-211 TER-211 V 560 EPR-17 9
B-10724-130 1 050 TER-134 TER-134 V 460 EPR-17
B-10724-130 1 050 TER-136 TER-136 V 520 –
– 6) – TER-215 TER-215 V 515 EPR-19
B-10724-140 950 TER-142 TER-142 V 435 EPR-18
– 6) – TER-217 TER-217 V 435 EPR-19
B-10724-144 925 TER-144 TER-144 V – –
B-10724-148 875 TER-146 TER-146 V 475 EPR-19
B-10724-148 875 TER-147 TER-147 V 475 EPR-19
B-10724-148 875 TER-148 TER-148 V 475 EPR-19
B-10724-148 875 TER-149 TER-149 V 475 EPR-19
– 6) – TER-220 TER-220 V 475 EPR-26
B-10724-151 850 TER-151 TER-151 V 460 –
B-10724-155 825 TER-154 TER-154 V 390 EPR-21
B-9784-130 750 TER-223 TER-223 V 390 EPR-21
– 6) – TER-224 TER-224 V 440 EPR-21
B-10724-155 825 TER-156 TER-156 V 435 –
– 6) – TER-225 TER-225 V 435 –
B-9784-140 800 TER-228 TER-228 V 425 EPR-22
B-9784-141 700 TER-229 TER-229 V 365 EPR-22
– 6) – TER-230 TER-230 V 410 –
B-9784-146 650 TER-233 TER-233 V 350 EPR-23
B-17024-167 725 TER-165 TER-165 V 390 –
B-9784-148 750 TER-234 TER-234 V 390 –
– 6) – TER-236 TER-236 V 385 EPR-24
– 6) – TER-239 TER-239 V 315 EPR-25
– 6) – TER-240 TER-240 V 365 –
B-9784-159 650 TER-244 TER-244 V 350 –
– 6) – TER-248 TER-248 V 315 –
4) For stepped shaft housing designs, the largest shaft diameter defines the speed limit.
5) Most taconite seals are made to order; contact SKF for availability, all V ring versions are made to order.
6) For more information contact the SKF application engineering service.
