2.3
N
G A 1 N 1
H 2
J
L
Shaft diameter Dimensions Mass
Ho using
1) 1) A H J L N G
d a d b d c d c A 1 C a D a H 1 H 2 N 1
min max
mm mm kg
55 65 95 70 44 100 129 70 28 210 255 24 18 16 5,85
64 64
65 95 70 44 100 129 70 28 210 255 24 18 16 5,45
64 64
65 – – 110 80 51 120 150 80 30 230 275 24 18 16 7,90
60 70 105 70 48 110 134 70 30 210 255 24 18 16 5,80
69 69
70 105 70 48 110 134 70 30 210 255 24 18 16 6,15
69 69
70 – – 115 80 56 130 156 80 30 230 280 24 18 16 8,55
1) Valid for some sealed spherical roller bearings only.
