Designs and variants
Designs and Sealed bearings

variants Sealed bearings equipped with contact seals
on both sides (ig. 6) are available:

SKF standard assortment • in the 22 and 23 series
• with bore diameter 10 ≤ d ≤ 70 mm
SKF self-aligning ball bearing variants are: • with seals made of sheet steel reinforced
NBR (oil and wear-resistant, designation
• open (ig. 2) sufix -2RS1)
– with cylindrical bore
– with tapered bore, e g for use with Permissible angular misalignment of sealed
adapter sleeves (ig. 3) bearings is slightly reduced compared to
– with extended inner ring (ig. 4) open design bearings
• sealed (ig. 5) 4
– with cylindrical bore
– with tapered bore, e g for use with
adapter sleeves

Fig. 2 Fig. 4
Open bearing Bearing with an extended inner ring

Fig. 3 Fig. 5 Fig. 6
Bearing on adapter sleeve with a lock nut Sealed bearing Contact seal on both sides

439
