Ordering information

Ordering information

For SE housings in the 2, 3, 5 and 6 series, 3
each of the following items must be ordered
separately:
• housing
• seals
• end cover
• locating rings
• bearing
• adapter sleeve
Order example
Two plummer block housings with four-lip
seals are required for a 22212 EK spherical
roller bearing on an H 3 12 adapter sleeve and
a C 2212 KTN9 CARB toroidal roller bearing
on an H 312 E adapter sleeve. One housing will
accommodate the non-locating bearing at the
end of the shaft. The other housing will
accommodate the locating bearing and a
through shaft.
The following items should be ordered (in
addition to the bearings and adapter sleeves):
• 2 housings SE 512-610
• 2 four-lip seal packs TSN 512 L
(each pack contains two seals)
• 1 end cover ASNH 5 12-610
• 4 locating rings FRB 10/110
