Bearing data

Bearing data, continued

Permissible Static misalignment
misalignment Insert bearings can accommodate static initial misalignment by tilting in the housing (ig. 2, page 340) The 2
permissible values are:
• SKF housings
– relubrication is not required: 5°
– relubrication is required (where applicable): 2°
• SKF pressed steel housings
– Misalignment cannot be accommodated once the attachment bolts have been fully tightened, unless a
rubber seating ring is used (page 347)

Dynamic misalignment
Insert bearings can accommodate a few minutes of arc (misalignment) between the inner and outer rings

351
